● Slim head design allows for access to hard to reach areas.
● Precision Forged ratchet yoke made of Cr-Mo alloy steel with optimized heat
treatment and maintain peak performance.
● Powerful compact ratchet with working torque.
treatment and maintain peak performance.
● Powerful compact ratchet with working torque.
● Precision machined anvil ensures that ratchet pawl and yoke can properly engage
with each other at any position.
with each other at any position.
● Variable speed trigger, adjustable air regulator.
|
Square Drive |
Speed (Free Speed) |
Max Torque |
Air Inlet |
Max Pressure |
Suggestion Air Hose (Inside Dia.) |
Net Weight |
Overall Length |
| in | rpm |
ft.lbs @90psi |
PT/NPT | psi | in(mm) | lbs.(kg) | in(cm) |
| 3/8 | 240 | 30 | 1/4" | 90 | 3/8(10) | 1.1(0.5) | 6.8(17.2) |
